ZPrinter
®
350 / ZPrinter
®
450 User Manual ZPrinter 350 and ZPrinter 450 Overview
3dscentral.3dsystems.com 2 All Rights Reserved
10/31/12
1.2 Specifications
Printer Dimensions and Type • With top cover closed: 48” wide x 31” deep x 55”
high. (122cm wide x 79cm deep x 140cm high)
• With top cover open: 48” wide x 31” deep x 72.3”
high. (122cm wide x 79cm deep x 183cm high)
• Floor standing model on four casters. The front two
casters are lockable.
• Integrated vacuum system.
• Integrated fine powder removal chamber.
• Full color capability; color shell thickness = .025”
(ZPrinter 450 only)
Printer Weight 425 lbs., 193 kg.
Network Connectivity TCP/IP 100/10 Base T
Operating Environment
Ambient Temperatures
Ambient Relative Humidity
• Maximum Temp. Range: 50-85° F (10 - 29.4° C)
• Recommended Temp. Range: 55-80° F (12.7 - 26.6°
C)
• Maximum RH Range: 15 - 70%, non-condensing
• Recommended RH Range: 20 - 60%, non-condens-
ing
(May experience sub-optimal performance at extremes.)
Build Volume 8” x 10” x 8” (203 mm x 254 mm x 203 mm)
640 cubic inches build capacity
Build Speed 2-4 layers per minute
Layer Thickness .0035” - .004” (.089 - .102 mm)
Resolution 300 x 450 dpi print resolution
Noise Levels During Printing = 57dB
Emptying Overflow = 66dB
Vacuuming - Cover Open = 86dB
Fine Powder Removal = 80dB
CSA, CE Approval Meets CE certification standards and UL standards.
