Technical Information DFS 700 / 04.2009 3-1
3 Overview of the Device
Figure 3-1 Overall View DFS 700
1 Frame with reflective coating (Diamond Grade, white)
2 Sensor to measure environmental brightness
3 Speed-display device
4 Radar sensor
5 LED-display bar, red and green-coloured
6 Mounting brackets, top and bottom (shorter), with fixing cuffs and bolts
7 Power Supply Unit box 230 V with mounting plate (optional accessory)
8 Ventilation fittings
9 Rotary hinge for attachment to the optional Battery- & Mounting Box.
10 Bolts for lock on the optional Battery- & Mounting Box.
11 Top service cover
12 Bottom service cover
13 12 V connection cable for DFS 700 power supply from the Power Supply Unit box.
14 Mains connector cable 230 V (see Safety Provisions Section 2)
15 Identification label
1
2
3
4
5
6
7
8
8
8
6
6
9
3
10
11
12
13
14
15
15
