3M DFS 700

Technical Information DFS 700 / 04.2009 6-8
6.4 Configuring the DFS 700 with a PC
All settings on the DFS 700 are made using the supplied DFS-CAS PC program. This program
is used to perform configuration and data analysis. Furthermore, diagnostic info and traffic
data can also be retrieved.
6.4.1 Install the DFS-CAS program
Minimum requirements
• PC with Intel Pentium III processor
• 256 MB RAM memory
• Display-/ Monitor resolution 1024x768
• CD-ROM drive
• USB (or Bluetooth) port
• 50 MB free disk space
• Windows 2000 SP4 or Windows XP SP2 operating system
• Internet Explorer 5.0.
Installation
(1) Insert the program CD in the drive - the Setup program starts automatically.
(2) Select “Install DFS-CAS for Windows“ or select “Start” then “Run” from the Windows
taskbar and enter the path to the CD ROM drive and the setup program file name, e.g.
“d:\setup.exe”, to open it
(3) Click “OK” to confirm. The program is installed, in doing so follow the installation
instructions.
(4) Once installation is complete the program can be started by the new symbol on the
desktop or by selecting it via the “Programs” menu.
(5) After the first start a window appears (Figure 6-7), in which the path for the data folder
and the desired language can be selected in advance.
