(5) Tighten the antenna head (Figure 6-6 Item 7) from inside with the hexagonal nut (Figure
6-6 Item 9). Ensure that the washer (Figure 6-6 Item 8) fully covers the hole from the
inside.
(6) Screw the antenna cable tightly to the antenna connection (Figure 6-6 Item 13).
(7) Screw the data cable (Figure 6-6 Item 12) to the RS 232 interface (Figure 6-6 Item 14).
(8) Plug the power cable to the DFS 700 into the socket (Figure 6-6 Item 15).
(9) Collect excess cable and tie off with cable ties.
(10) Insert an activated GSM data SIM card into the SIM card holder (Figure 6-6 Item 16) in
the GSM/GPRS Modem and lock it.
See Section 4.5 for information on the SIM card to be used.
