Technical Information DFS 700 / 04.2009 10-1

10 Technical Data

DFS 700 – Complete system

• Dimensions in mm................................................................660 wide x 770 high x 110 deep

• Weight ...........................................................................................................................8.5 kg

Speed-display device

• Line voltage....................................................................................................11.3 V – 15.0 V

• Electrical power

Standby mode.......................................................................................... 0.02 A (0.24 W)

Radar mode with inactive display ............................................................ 0.08 A (0.96 W)

Radar mode with active single-colour display............................................. 1.00 A (12 W)

Maximum power .............................................................................................. 5 A (60 W)

(less than 1 second with all active components)

• Fuse .............................................................................................ATO 4A Delay Action Fuse

• Case ingress protection..................................................................................................IP 54

• Case colour ............................................................................................................ RAL 7042

• Permissible ambient temperature (in the casing) ...............................................-35 to +75°C

• Permissible humidity .............................................................................................. up to 95%

• Digital display .............................................................................. 330 mm high 450 mm wide

2 1/2-digital display with 13 segments, highest displayable value: 199

• LEDs ...................................................................................................... InGaAIP SMD LEDs

Viewving angle 16° to 18°

3 rows green LEDs (570 mm)

3 rows red LEDs (635 mm)

• Buffer battery for real-time clock............................................................ 3 V CR 2450 Lithium

Durability approx. 2 years

• Data storage

Non-volatile memory.................................................................................................1 MB

Data inputs...................................................................................................max. 100,000

• Radar frequency............................................................................... 24.15 GHz – 24.25 GHz

• Radar output................................................................................................20 dBm, 100 mW
