3M DFS 700

Technical Information DFS 700 / 04.2009 6-1
1
2
2
3
or/and
Preliminaries
Configuration
with PC
Configuration
with PC and PDA
Operation
PC
CD
DFS-CAS
Windows 2000/XP
PC
CD
DFS-CAS
Windows Mobile
Power
Power
PDA
PDA
USB
USB
Driver
USB
Bluetooth
Bluetooth
Driver
Power
6 Preparation and Configuration
6.1 Overview of first comissioning
These images show the sequence of the first use up to operation of the standard model DFS
700 (Figure 6-1) and DFS 700 with optional accessories (Figure 6-2) in simplified form.
The individual working steps are listed and explained in detail in the following sections.
Figure 6-1 Commissioning DFS 700 standard model
