3M DFS 700

Technical Information DFS 700 / 04.2009 3-3
1
2
3
4
5
4C
4D
4B
4A
Optional accessories for the DFS 700
Figure 3-3 Optional accessories for the DFS 700
1 Battery- & Mounting Box
2 Battery 12 V, 17Ah with cable
3 Battery Charger with mounting set and operating instructions, 12 V charging cable and
mains connector cable 230 V (see Safety Provisions Section 2)
4 GSM/GPRS Modem with mounting set
4A GSM-Antenna
4B SIM-card insert
4C Connector for GSM-data cable
4D Connector for GSM power supply cable
5 EU-Universal plug for connecting the Battery Charger (only indoors!)
6 Power Supply Unit box with mounting plate, 12 V power chord for DFS 700
and mains connector cable 230 V (see Safety Provisions Section 2)
66
