The description of the table is shown below:
ITEM
DESCRIPTION
System
System Name
The name provided in System Information.
Firmware Version
The present firmware version of the system.
Build Number
The Build Number of the firmware.
Location
The location provided in System Information.
Site
The firmware version for specific region.
Device Time
The current time on the device.
System Up Time
The system elapsing time since last reboot.
CPU/RAM Usage
The system’s resource usage (CPU Utilization and RAM usage)
Operating Mode
Either CPE or AP.
LAN Interface
MAC Address
The MAC address of LAN Interface.
IP Address
The IP address of the LAN Interface.
Subnet Mask
The Subnet Mask of the LAN Interface.
DHCP Server
DHCP server status.
Radio Status
Status
The RF status.
SSID
The SSID of the associated AP.
MAC Address
The MAC address of the associated AP.
Channel
The operating channel.
Signal Strength
The signal strength reading of the wireless connection.
Security
The security type used for wireless connection.
WAN Status
Mode
The method to obtain IP for the WAN interface.
MAC Address
The MAC address of the WAN (RF) Interface.
IP Address
The IP address of the WAN interface.
Subnet Mask
The Subnet Mask of the WAN interface.
Gateway
The gateway IP address.
Bandwidth
The bandwidth setting of the WAN interface.
The system supports graph displays of CPU/RAM usage and Signal Strength RSSI on the status page.
The Time Axis is configurable with the following options: 1 minute, 2 minutes, 5 minutes, or 10 minutes. Left
click on the mouse to zoom in on desired regions. Double click to return the plot to its original scale.
