M512-3 Juggler : User Guide © 2021 7thSense
External Control
<memberarrayitem UUID="04e120c5000000000400000000000168" value="Lock to Rx:3"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000169" value="Lock to Rx:4"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000170" value="Lock to Tx:1"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000171" value="Lock to Tx:2"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000172" value="Lock to Tx:3"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000173" value="Lock to Tx:4"
enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000174" value="Lock to
GPIO:1" enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000175" value="Lock to
GPIO:2" enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000176" value="Lock to
GPIO:3" enabled="1"/>
<memberarrayitem UUID="04e120c5000000000400000000000177" value="Lock to
GPIO:4" enabled="1"/>
</genlockconfig>
</replies>
Hotplug Detect
Simulate removal and reinsertion of HDMI output
Command
<command cmd="set" path="/GroupSet/Group/JugglerName/HdmiTx:3/triggerhpd"
value="1"/>
Reply
<set success="true"/>
EDID Lists
Get current EDID selection and EDID list
Command
<command cmd="get" path="/GroupSet/Group/JugglerName/DpRx:2/edidlist"/>
