M512-3 Juggler : User Guide © 2021 7thSense
Front Panel: Controls
Video tab
This tab provides a direct NDI display of media being processed by the unit, as a row of video
channels 1 to 4.
Info tab
This shows the Juggler name, IP addresses, network mode, Project name and connection status, and
a second swipe-to page for editing the static IP address and subnet.
Set Juggler Static IP and Subnet
This can be done from the Juggler front panel touch screen.
· Touch to select ‘Info’ tab if it is not already showing.
· Swipe from right to left to move to the IP Editor page:
· Touch to select an octet (address element) to change; it will show highlighted blue.
· Use the number pad on the left to enter a value up to 255.
