Page #100 background imageLoading...
Page #100 background image
100
M512-3 Juggler : User Guide
© 2021 7thSense
Nodes: Connecting Juggler Systems
Input / Output Connector Properties
Each Juggler module is delivered with firmware capable of the hardware functionality purchased. The
firmware determines how each module will be seen in Compere and can be programmed. The
Compere software manages what functionality can be configured, per Juggler module.
Ø
For some typical configurations, see: Input and Output Options
Select a Juggler in the Project and expanded its branch to list its individual elements. Each can be
selected for its properties. Alternatively, select the Juggler and expand and collapse its parts in the
Properties panel.
Channel Input/Output Properties
There are a total of four Channels, numbered 1-4, in every Juggler. For example, two of these may be
allocated as an 8-lane bus, and two as HDMI. The number and type of inputs and outputs on each
Juggler module is detected and listed in the Juggler’s properties in Compere.
·
DisplayPort connectors marked DPRx and DPTx, numbered 1 to 4
·
HDMI connectors marked HDMIRx and HDMITx, numbered 1 to 4
·
SDI connectors marked SDIRx and SDITx, numbered 1 to 4.
·
Data bus connectors marked BusRx and BusTx, numbered 1 to 4
