BM series 31
6.5.2. Controlling the Ionizer Externally
It is possible to control the BM ionizer function by connecting the remote controller
(AD-8922A) or the foot switch (AX-SW137-PRINT, AX-SW137-REZERO).
When specifying "on" to “AD-8922A control (8922)” in the
function table (ionfnc 8922 on), the balance assigns the
function of the ION key to the MODE key on the AD-
8922A.
When specifying “External control input (e-5)” in “Ionizer function (ionfnc)”, the following
functions can be assigned to AX-SW137-PRINT (option) or AX-SW137-REZERO (option)
terminals.
Ionizer function External control input AX-SW137-PRINT AX-SW137-REZERO
ionfnc e-5 0 PRINT key RE-ZERO key
ionfnc e-5 1 PRINT key ION key
ionfnc e-5 2 ION key RE-ZERO key
Factory settings
A
ssign the ION key
to the MODE key on
the AD-8922A.
