ContentsChapter
Calibration procedures and general information about calibration.Calibration
Environmental information about the robot and its components.Decommissioning
Useful information when performing installation, maintenance
or repair work. Includes lists of necessary tools, additional doc-
uments, safety standards, etc.
Reference information
Reference to the spare part list for the robot.Spare parts and exploded
views
Reference to the circuit diagram for the robot.Circuit diagram
References
Documentation referred to in the manual, is listed in the table below.
Document IDDocument name
3HAC064429-001Product manual, spare parts - IRB 6790
3HAC064168-001Product specification - IRB 6790
3HAC048484-002Directions for use - Fork lift accessory for IRB 6700
3HAC043446-005Circuit diagram - IRB 6700 / IRB 6790
3HAC031045-001Safety manual for robot - Manipulator and IRC5 or OmniCore con-
troller
i
3HAC047136-001Product manual - IRC5
IRC5 with main computer DSQC1000.
3HAC021313-001IRC5 with main computer DSQC 639.
3HAC050941-001Operating manual - IRC5 with FlexPendant
3HAC042927-001Technical reference manual - Lubrication in gearboxes
3HAC050948-001Technical reference manual - System parameters
i
This manual contains all safety instructions from the product manuals for the manipulators and the
controllers.
Revisions
DescriptionRevision
First edition.A
Continues on next page
10 Product manual - IRB 6790
3HAC063331-001 Revision: B
© Copyright 2019 - 2020 ABB. All rights reserved.
