2.4.5 Orienting and securing the robot
General
This section details how to orient and secure the robot to the base plate in order
to run the robot safely.
Hole configuration, base
The figure shows the hole configuration used when positioning and securing the
robot.
D - D
8x
3
0
8x
5
3
4x 45 H7
4x 3x45
16
8x
49,5
0,3 A
0,12
A
800
4x
90°
52,5°
4x
15°
D
D
E
E
2x 25 H8
20 (
25 H8)
2x45°
24,5
2x
0,12
E - E
(A)
(A)
xx1300000243
DescriptionPos
Holes for guide pins (x2)A
