Brief description of calibration methods
Axis Calibration method
Axis Calibration is a standard calibration method for calibration of IRB 6790 and
is the most accurate method for the standard calibration. It is the recommended
method in order to achieve proper performance.
The following routines are available for the Axis Calibration method:
• Fine calibration
• Update revolution counters
• Reference calibration
The calibration equipment for Axis Calibration is delivered as a toolkit.
An introduction to the calibration method is given in this manual, see Calibrating
with Axis Calibration method on page 623.
The actual instructions of how to perform the calibration procedure and what to
do at each step is given on the FlexPendant. You will be guided through the
calibration procedure, step by step.
CalibWare - Absolute Accuracy calibration
The CalibWare tool guides through the calibration process and calculates new
compensation parameters. This is further detailed in the Application
manual - CalibWare Field.
If a service operation is done to a robot with the option Absolute Accuracy, a new
absolute accuracy calibration is required in order to establish full performance.
For most cases after replacements that do not include taking apart the robot
structure, standard calibration is sufficient.
References
Article numbers for the calibration tools are listed in the section Special tools on
page 653.
