Maintenance / Repair
IM/265D/V-EN-02 265Dx, 265VS 81
Pos: 25.8 /Wart ung / Reparatur/Druck/Dr uckmessumformer/ Druckmessumformer 265Dx , 265Vx/Demontage der Elek tronik @ 17\mod_12011724 91953_3101.doc @ 154127
12.1.2 Removing the electronics
If the electronics housing needs to be unscrewed from the measuring equipment/measuring
cell, the electronics must first be removed from their housing to prevent them from being
damaged.
1. First, unscrew the housing cover.
Important
Please note that a locking screw is used (see "Securing the housing cover with EEx d").
2. Following this, remove the LCD display (if present) from the electronics. To do this, slacken
the two screws.
3. Slacken the two fixing screws for the electronics and carefully remove the electronics from
their housing.
4. Remove both plugs from the electronics. Both plugs feature mechanical polarity protection,
and the smaller of the two also has a mechanical locking device.
5. Grasp the two plugs from the front between your thumb and forefinger, and push them
together. This opens the locking device.
6. Pull the plug out of the socket. Place the electronics on a suitable surface.
7. Unscrew the electronics housing from the measuring equipment/measuring cell.
