156 Actual signals and parameters
0303
FB STS WORD 1
-1- hex
Read-only copy of the Status word 1.
• The drive sends status information to the fieldbus controller. The status consists of
two Status words.
0304
FB STS WORD 2
-1- hex
Read-only copy of the Status word 2.
• See parameter 0303 FB STS WORD 1.
Group 03: FB actual signals
Code Description Range Resolution Default S
Bit # 0303 STS CMD WORD 1 0304 FB STS WORD 2
0 READY ALARM
1 ENABLED REQ_MAINT
2 STARTED DIRLOCK
3 RUNNING LOCALLOCK
4 ZERO_SPEED CTL_MODE
5 ACCELERATE Reserved
6 DECELERATE MOTORHEAT
7 AT_SETPOINT Reserved
8 LIMIT Reserved
9 SUPERVISION Reserved
10 REV_REF REQ_CTL
11 REV_ACT REQ_REF1
12 PANEL_LOCAL REQ_REF2
13 FIELDBUS_LOCAL REQ_REF2EXT
14 EXT2_ACT ACK_STARTINH
15 FAULT ACK_OFF_ILCK
