Actual signals and parameters 223
3626
TIMER 1 SRC
0…48 1 0
Defines the time periods used by the timer.
0 = NOT SEL- No timers have been selected.
1 = P1 – Time Period 1 selected in the timer.
2 = P2 – Time Period 2 selected in the timer.
3 = P1+P2 – Time Periods 1 and 2 selected in the timer.
4 = P3 – Time Period 3 selected in the timer.
5 = P1+P3 – Time Periods 1 and 3 selected in the timer.
6 = P2+P3 – Time Periods 2 and 3 selected in the timer.
7 = P1+P2+P3 – Time Periods 1, 2 and 3 selected in the timer.
8 = P4 – Time Period 4 selected in the timer.
9 = P1+P4 – Time Periods 4 and 1 selected in the timer.
10 = P2+P4 – Time Periods 4 and 2 selected in the timer.
11 = P1+P2+P4 – Time Periods 4, 2 and 1 selected in the timer.
12 = P3+P4 – Time Periods 4 and 3 selected in the timer.
13 = P1+P3+P4 – Time Periods 4, 3 and 1 selected in the timer.
14 = P2+P3+P4 – Time Periods 4, 3 and 2 selected in the timer.
15 = P1+P2+P3+P4 – Time Periods 4, 3, 2 and 1 selected in the timer.
16 = BOOST – Booster selected in the timer.
17 = P1+B – Booster and Time Period 1 selected in the timer.
18 = P2+B – Booster and Time Period 2 selected in the timer.
19 = P1+P2 B – Booster and Time Periods 1 and 2 selected in the timer.
20 = P3+B – Booster and Time Period 3 selected in the timer function.
21 = P1+P3+B – Booster and Time Period 3 and 1 selected in the timer.
22 = P2+P3+B – Booster and Time Periods 3 and 2 selected in the timer.
23 = P1+P2+P3+B – Booster and Time Periods 3, 2 and 1 selected in the timer.
24 = P4+B – Booster and Time Periods 4 selected in the timer.
25 = P1+P4+B – Booster and Time Period 4 and Timer 1 selected in the timer.
26 = P2+P4+B – Booster and Time Period 4 and 2 selected in the timer.
27 = P1+P2+P4+B – Booster and Time Periods 4, 2 and 1 selected in the timer.
28 = P3+P4+B – Booster and Time Periods 4 and 3.
29 = P1+P3+P4+B – Booster and Time Periods 4, 3 and 1 selected in the timer.
30 = P2+P3+P4+B – Booster and Time Periods 4, 3 and 2 selected.
31 = P1+2+3+4+B – Booster and Time Periods 4, 3, 2 and 1 selected.
32 = ALTERNATING – Alternating time period is enabled. All other time periods P1,
P2, P1+P2 and P3 are ignored (for the specific timed function).
48 = ALT+BOOSTER – Alternating time period and booster timer are enabled
simultaneously.
3627
TIMER 2 SRC
0…48 1 0
See parameter 3626.
3628
TIMER 3 SRC
0…48 1 0
See parameter 3626.
3629
TIMER 4 SRC
0…48 1 0
See parameter 3626.
Group 36: Timed functions
Code Description Range Resolution Default S
