272 Actual signals and parameters
2 = DI2 – Enables the Interlock function, and assigns a digital input (starting with DI2)
to the interlock signal for each PFA relay. These assignments are defined in the
following table and depend on:
• The number of PFA relays (number of parameters 1401…1403 and 1410) with
value = 31 (PFA).
• The Autochange function status (disabled if 8118 AUTOCHNG INTERV = 0, and
otherwise enabled).
Note: MREL-01 required for PFA relays 2, 3 and 4.
3 = DI3 – Enables the Interlocks function, and assigns a digital input (starting with DI3)
to the interlock signal for each PFA relay. These assignments are defined in the
following table and depend on:
• The number of PFA relays (number of parameters 1401…1403 and 1410) with
value = 31 (PFA).
• The Autochange function status (disabled if 8118 AUTOCHNG INTERV = 0, and
otherwise enabled).
Group 81: PFA control
Code Description Range Resolution Default S
No. PFA relays Autochange disabled (8118) Autochange enabled (8118)
0DI1: Free
DI2: Speed Reg Motor
DI3…DI5: Free
Not allowed
1DI1: Free
DI2: Speed Reg Motor
DI3: First PFA Relay
DI4…DI5: Free
DI1: Free
DI2: First PFA Relay
DI3…DI5: Free
2DI1: Free
DI2: Speed Reg Motor
DI3: First PFA Relay
DI4: Second PFA Relay
DI5…DI5: Free
DI1: Free
DI2: First PFA Relay
DI3: Second PFA Relay
DI4…DI5: Free
3DI1: Free
DI2: Speed Reg Motor
DI3: First PFA Relay
DI4: Second PFA Relay
DI5: Third PFA Relay
DI1: Free
DI2: First PFA Relay
DI3: Second PFA Relay
DI4: Third PFA Relay
DI5…DI5: Free
4DI1: Free
DI2: Speed Reg Motor
DI3: First PFA Relay
DI4: Second PFA Relay
DI5: Third PFA Relay
DI1: Free
DI2: First PFA Relay
DI3: Second PFA Relay
DI4: Third PFA Relay
DI5: Fourth PFA Relay
