304 Fieldbus control
Metasys integration
The following diagram shows the drives’ integration to the Johnson Controls Metasys
system.
The following diagram shows the drives’ integration to the Johnson Controls Metasys
Companion system.
N1LAN
NCU
N2 Fieldbus
PC-Version
Converter
Panel Version/LTD
N2 Fieldbus
PC Version
Panel Version/LTD
RS232 -EIA-485 Converter
