Fieldbus control 323
65...
67
N/A
68 FLN LOC CTL Commanded by FLN to temporarily “steal” start/stop
control of the drive from its normal source and place it
under FLN control. This functionality is analogous to
placing the drive in HAND mode at the panel, with the
control being taken by FLN instead. HAND mode at the
panel has priority over this point. Thus, this point is only
effective in temporarily taking control from the digital
inputs or some other internal control functionality.
69 FLN LOC REF Commanded by FLN to temporarily “steal” input
reference control of the drive from its normal source and
place it under FLN control. This functionality is
analogous to placing the drive in HAND mode at the
panel, with the reference control being taken by FLN
instead. HAND mode at the panel has priority over this
point. Thus, this point is only effective in temporarily
taking control from the analog inputs or some other
internal control functionality.
70...
81
N/A
82 AI 1 ACTUAL Indicates the input level of Analog Input 1. 0120
83 AI 2 ACTUAL Indicates the input level of Analog Input 2. 0121
84 AO 1 ACTUAL Indicates the output level of Analog Output 1. 0124
85 N/A
86 OK.ALARM Indicates the current alarm state of the drive
(1 = ALARM, 0 = OK).
87 OK.MAINT Indicates the current maintenance state of the drive
(1 = MAINT, 0 = OK).
Maintenance triggers are configured in drive parameter
Group 29.
88 ALARM WORD1 This point is a bit-field indicating active alarms in the
drive.
0308
89 ALARM WORD2 This point is a bit-field indicating active alarms in the
drive.
0309
90 LAST FAULT This point is first in the drive's fault log and indicates the
most recent fault declared.
0401
91 PREV FAULT 1 This point is second in the drive's fault log and indicates
the previous fault declared.
0412
92 PREV FAULT 2 This point is last in the drive's fault log and indicates the
oldest fault in the log.
0413
93 OK.FAULT Indicates the current fault state of the drive
(1 = FAULT, 0 = OK).
FLN Detailed Point Descriptions
Point Description
Drive
Parameter
