200 Actual signals and parameters
OVERVOLTAG
E
Alarm/Fault by overvoltage protection function 22
DRIVE TEMP Alarm/Fault by drive overtemperature protection function 23
UNDERVOLTA
GE
Alarm/Fault by undervoltage protection function 24
AI1 LOSS Analog input AI1 signal is lost. 25
AI2 LOSS Analog input AI2 signal is lost. 26
MOTOR TEMP Alarm/Fault by motor overtemperature protection function.
See parameter 3005 MOT THERM PROT.
27
STALL Alarm/Fault by stall protection function. See parameter 3010
STALL FUNCTION.
28
UNDERLOAD Alarm/Fault by underload protection function. See
parameter 3013 UNDERLOAD FUNC.
29
PID SLEEP PID sleep function. See parameter group 40 PROCESS PID
SET 1 / 41 PROCESS PID SET 2.
30
FLUX READY Motor is magnetized and able to supply nominal torque. 33
USER MACRO
2
User macro 2 is active. 34
COMM Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
35
COMM(-1) Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
36
TIMED FUNC 1 Timed function 1 is active. See parameter group 36 TIMED
FUNCTIONS.
37
TIMED FUNC 2 Timed function 2 is active. See parameter group 36 TIMED
FUNCTIONS.
38
All parameters
No. Name/Value Description Def/FbEq
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 0 0 0 0 0
1 00001 0 0 0 0 1
2 00010 0 0 0 1 0
30001100011
4 00100 0 0 1 0 0
5…30 … … … … … …
31 11111 1 1 1 1 1
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 1 1 1 1 1
1 00001 1 1 1 1 0
2 00010 1 1 1 0 1
30001111100
4 00100 1 1 0 1 1
5…30 … … … … … …
31 11111 0 0 0 0 0
