Actual signals and parameters 211
DI1 Timer start through digital input DI1. Timer start on the rising
edge of digital input DI1.
Note: Timer start is not possible when reset is active
(parameter 1903 TIMER RESET).
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
START External start signal, eg start signal through fieldbus 6
1903 TIMER RESET Selects the source for the timer reset signal. NOT SEL
DI1(INV) Timer reset through inverted digital input DI1. 0 = active, 1 =
inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No reset signal 0
DI1 Timer reset through digital input DI1. 1 = active, 0 = inactive. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
START Timer reset at start. Start signal source is selected by
parameter 1902 TIMER START.
6
START (INV) Time reset at start (inverted), ie timer is reset when start
signal is deactivated. Start signal source is selected by
parameter 1902 TIMER START.
7
RESET External reset, eg reset through fieldbus 8
1904 COUNTER
ENABLE
Selects the source for the counter enable signal. DISABLE
D
DI1(INV) Counter enable signal through inverted digital input DI1. 0 =
active, 1 = inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
DISABLED No counter enable 0
DI1 Counter enable signal through digital input DI1. 1 = active, 0
= inactive.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
All parameters
No. Name/Value Description Def/FbEq
