212 Actual signals and parameters
DI5 See selection DI1.5
ENABLED Counter enabled 6
1905 COUNTER
LIMIT
Defines the counter limit. 1000
0…65535 Limit value 1 = 1
1906 COUNTER
INPUT
Selects the input signal source for the counter. PLS IN(DI
5)
PLS IN(DI 5) Digital input DI5 pulses. When a pulse is detected, the
counter value increases by 1.
1
ENC W/O DIR Encoder pulse edges. When a rising or a falling edge is
detected, the counter value increases by 1.
2
ENC WITH DIR Encoder pulse edges. The direction of rotation is taken into
account. When a rising or a falling edge is detected and the
direction of rotation is forward, the counter value increases
by 1. When the direction of rotation is reverse, the counter
value decreases by 1.
3
FILTERED DI5 Filtered digital input DI5 pulses. When a pulse is detected,
the counter value increases by 1.
Note: Due to filtering, the maximum input signal frequency
is 50 Hz.
4
1907 COUNTER
RESET
Selects the source for the counter reset signal. NOT SEL
DI1(INV) Counter reset through inverted digital input DI1. 0 = active, 1
= inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No reset signal 0
DI1 Counter reset through digital input DI1. 1 = active, 0 =
inactive.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
AT LIMIT Reset at the limit defined by parameter 1905 COUNTER
LIMIT
6
STRT/STP
CMD
Counter reset at start/stop command. Source for the
start/stop is selected by parameter 1911 CNTR S/S
COMMAND.
7
S/S CMD(INV) Counter reset at start/stop command (inverted), ie counter is
reset when start/stop command is deactivated. Start signal
source is selected by parameter 1902 TIMER START.
8
