Actual signals and parameters 213
RESET Reset enabled 9
1908 COUNTER
RES VAL
Defines the value for the counter after reset. 0
0…65535 Counter value 1 = 1
1909 COUNT
DIVIDER
Defines the divider for the pulse counter. 0
0…12 Pulse counter divider N. Every 2
N
bit is counted. 1 = 1
1910 COUNT
DIRECTION
Defines the source for the counter direction selection. UP
DI1(INV) Counter direction selection through inverted digital input
DI1. 1 = counts up, 0 = counts down.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
UP Counts up 0
DI1 Counter direction selection through digital input DI1. 0 =
counts up, 1 = counts down.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DOWN Counts down 6
1911 CNTR S/S
COMMAND
Selects the source for the drive start/stop command when
parameter 1001 EXT1 COMMANDS value is set to
COUNTER START / COUNTER STOP.
NOT SEL
DI1(INV) Start/stop command through inverted digital input DI1.
When parameter 1001 EXT1 COMMANDS value is
COUNTER STOP: 0 = start. Stop when counter limit defined
by parameter 1905 COUNTER LIMIT has been exceeded.
When parameter 1001 value is COUNTER START: 0 =
stop. Start when counter limit defined by parameter 1905
has been exceeded.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL Not start/stop command source 0
All parameters
No. Name/Value Description Def/FbEq
