Fieldbus control with fieldbus adapter 329
1604 FAULT RESET
SEL
COMM Selects the fieldbus interface as the source for
the fault reset signal.
1606 LOCAL LOCK COMM Selects the fieldbus interface as the source for
the local lock signal.
1607 PARAM SAVE DONE
SAVE…
Saves parameter value changes (including
those made through fieldbus control) to the
permanent memory.
1608 START
ENABLE 1
COMM Selects the fieldbus interface as the source for
the inverted Start enable 1 (Start disable) signal.
1609 START
ENABLE 2
COMM Selects the fieldbus interface as the source for
the inverted Start enable 2 (Start disable) signal.
LIMITS
2013 MIN TORQUE
SEL
COMM Selects the fieldbus interface as the source for
the minimum torque limit 1/2 selection.
2014 MAX TORQUE
SEL
COMM Selects the fieldbus interface as the source for
the maximum torque limit 1/2 selection.
2201 ACC/DEC 1/2
SEL
COMM Selects the fieldbus interface as the source for
acceleration/deceleration ramp pair 1/2
selection
2209 RAMP INPUT 0 COMM Selects the fieldbus interface as the source for
forcing ramp input to zero.
COMMUNICATION FAULT FUNCTIONS
3018 COMM FAULT
FUNC
NOT SEL
FAULT
CONST SP 7
LAST SPEED
Determines the drive action in case the fieldbus
communication is lost.
3019 COMM FAULT
TIME
0.1 … 60.0 s Defines the time between the communication
loss detection and the action selected with
parameter 3018 COMM FAULT FUNC.
PID CONTROLLER REFERENCE SIGNAL SOURCE SELECTION
4010/
4110/
4210
SET POINT
SEL
COMM
COMM+AI1
COMM*AI1
PID control reference (REF2)
Parameter Setting for
fieldbus control
Function/Information
