Control panels 97
4. Select the scalings for the signals by specifying the
minimum and maximum display values. This has no
effect if parameter 3404/3411/3418 is set to 9 (DIRECT).
For details, see parameters 3406 and 3407.
Signal 1: parameters 3406 OUTPUT1 MIN and 3407
OUTPUT1 MAX
Signal 2: parameters 3413 OUTPUT2 MIN and 3414
OUTPUT2 MAX
Signal 3: parameters 3420 OUTPUT3 MIN and 3421
OUTPUT3 MAX.
Step Action Display
3406 OUTPUT1 MIN
CANCEL
SAVE
00:00
LOC
0.0 Hz
PAR EDIT
3407 OUTPUT1 MAX
CANCEL
SAVE
00:00
LOC
500.0 Hz
PAR EDIT
