Transportation in the
protective package
Storage in the protective
package
Operation installed for
stationary use
Requirement
According to ISTA 1A.According to ISTA 1A.Not allowedShock/(IEC 60068-2-27,
ISTA 1A)
Max. 100 m/s
2
(330 ft/s
2
),
11 ms.
Max. 100 m/s
2
(330 ft/s
2
),
11 ms.
76 cm (30 in)76 cm (30 in)-Free fall
Materials
Hot-dip zinc coated steel sheet 1.5 mm (0.06 in). Extruded aluminum AlSi.
PC/ABS 2 mm (0.08 in), PC+10%GF 2.5…3 mm (0.10...0.12 in) and PA66+25%GF
1.5 mm (0.06 in), all in color NCS 1502-Y (RAL 9002 / PMS 420 C)
Drive enclosure
Corrugated cardboardPackage
Disposal
The main parts of the drive can be recycled to preserve natural resources and energy.
Product parts and materials should be dismantled and separated.
Generally all metals, such as steel, aluminum, copper and its alloys, and precious metals
can be recycled as material. Plastics, rubber, cardboard and other packaging material can
be used in energy recovery. Printed circuit boards and large electrolytic capacitors need
selective treatment according to IEC 62635 guidelines. To aid recycling, plastic parts are
marked with an appropriate identification code.
Contact your local ABB distributor for further information on environmental aspects and
recycling instructions for professional recyclers. End of life treatment must follow international
and local regulations.
Applicable standards
The drive complies with the following standards:
Safety of machinery – Safety related parts of the control systems – Part 1: general
principles for design
EN ISO 13849-1:2015
Safety of machinery – Safety-related parts of the control systems – Part 2: ValidationEN ISO 13849-2:2012
Safety of machinery. Electrical equipment of machines. Part 1: General require-
ments. Provisions for compliance: The final assembler of the machine is responsible
for installing
• an emergency-stop device
• a supply disconnecting device
EN 60204-1:2006 +
A1:2009 + AC:2010
Safety of machinery – Functional safety of safety-related electrical, electronic and
programmable electronic control systems
EN 62061:2005 + AC:2010
+ A1:2013 + A2:2015
Adjustable speed electrical power drive systems. Part 3: EMC requirements and
specific test methods
EN 61800-3:2004 +
A1:2012
IEC 61800-3:2004 +
A1:2011
Adjustable speed electrical power drive systems – Part 5-1: Safety requirements
– Electrical, thermal and energy
IEC/EN 61800-5-1:2007
UL Standard for adjustable speed electrical power drive systems – Part 5-1: Safety
requirements – Electrical, thermal and energy
ANSI/UL 61800-5-1:2015
Adjustable speed drivesCSA C22.2 No. 274-13
116 Technical data
