102 Control macros
The control macros are categorized as application macros and communication
macros.
Application macros
Application macros set the default parameters needed for certain industrial
applications.
The available application macros are:
• ABB standard macro
• ABB standard macro (vector)
• 3-wire macro
• Motor potentiometer macro
• PID macro
• Panel PID macro
• Torque control macro
• Pump and Fan Control (PFC) macro
• Soft Pump and Fan Control (SPFC) macro
• Pharma macro
• Plastic extrusion macro
• Jigar macro
ABB standard macro
ABB standard macro is the default macro
The macro has the following features:
• 2-wire I/O configuration with three constant frequency references
• Applicable for normal control purpose
• One signal is used to start or stop the motor and another signal is used to select
the direction
• Uses scalar control by default.
Note: For vector control you can use the ABB standard (vector) macro (page 105).
