ABB ACS560 - Process PID Set 2

Parameters 309
40.91 Feedback data
storage
Storage parameter for receiving a process feedback value
e.g. through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data. Set
the target selection parameter of that particular data
(58.101…58.114) to Feedback data storage. In 40.08 Set 1
feedback 1 source (or 40.09 Set 1 feedback 2 source), select
Feedback data storage.
0.00
-327.68…327.67 Storage parameter for process feedback. 100 = 1
40.92 Setpoint data
storage
Storage parameter for receiving a process setpoint value e.g.
through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data. Set
the target selection parameter of that particular data
(58.101…58.114)) to Setpoint data storage. In 40.16 Set 1
setpoint 1 source (or 40.17 Set 1 setpoint 2 source), select
Setpoint data storage.
0.00
-327.68…327.67 Storage parameter for process setpoint. 100 = 1
40.96 Process PID
output%
Percentage scaled signal of parameter 40.01 Process PID
feedback actual. Correct later.
0.00
-100.00...100.00% Percentage. 1=1
40.97 Process PID
feedback%
Percentage scaled signal of parameter 40.02 Process PID
feedback actual.
0.00
-100.00...100.00% Percentage. 1=1
40.98 Process PID
setpoint%
Percentage scaled signal of parameter 40.03 Process PID
setpoint actual.
0.00
-100.00...100.00% Percentage. 1=1
40.99 Process PID
deviation%
Percentage scaled signal of parameter 40.04 Process PID
deviation actual.
0.00
-100.00...100.00% Percentage. 1=1
41
41 Process PID set 2
A second set of parameter values for process PID control.
The selection between this set and first set (parameter group
40 Process PID set 1) is made by parameter 40.57 PID
set1/set2 selection.
See also parameters 40.01…40.06, and the control chain
diagrams on pages 495 and 498.
41.08 Set 2 feedback 1
source
See parameter 40.08 Set 1 feedback 1 source. AI2 percent
41.09 Set 2 feedback 2
source
See parameter 40.09 Set 1 feedback 2 source. Not selected
41.10 Set 2 feedback
function
See parameter 40.10 Set 1 feedback function. In1
41.11 Set 2 feedback filter
time
See parameter 40.11 Set 1 feedback filter time. 0.000 s
41.14 Set 2 setpoint
scaling
See parameter 40.14 Set 2 setpoint scaling.0.00
41.15 Set 2 output scaling See parameter 40.15 Set 2 output scaling.0.00
41.16 Set 2 setpoint 1
source
See parameter 40.16 Set 1 setpoint 1 source. AI1 percent
41.17 Set 2 setpoint 2
source
See parameter 40.17 Set 1 setpoint 2 source. Not selected
No. Name/Value Description Def/FbEq16
