306 Parameters
PID output PID controller output. 2
40.57 PID set1/set2
selection
Selects the source that determines whether process PID
parameter set 1 (parameters 40.07…40.50) or set 2 (group
41 Process PID set 2) is used.
PID set 1
PID set 1 0. Process PID parameter set 1 in use. 0
PID set 2 1. Process PID parameter set 2 in use. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 21
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 22
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 23
Other [bit] Source selection (see Terms and abbreviations on page 162). -
40.58 Set 1 increase
prevention
Prevention of PID integration term increase for PID set 1. No
No Increase prevention not in use. 0
Limiting The PID integration term is not increased if the maximum
value for the PID output is reached. This parameter is valid
for the PID set 1.
1
Ext PID min lim The process PID integration term is not increased when the
output of the external PID has reached its minimum limit. In
this setup, the external PID is used as a source for the
process PID. This parameter is valid for the PID set 1.
2
Ext PID max lim The process PID integration term is not increased when the
output of the external PID has reached its maximum limit. In
this setup, the external PID is used as a source for the
process PID. This parameter is valid for the PID set 1.
3
Other [bit] Source selection (see Terms and abbreviations on page 162). -
40.59 Set 1 decrease
prevention
Prevention of PID integration term decrease for PID set 1. No
No Decrease prevention not in use. 0
Limiting The PID integration term is not decreased if the minimum
value for the PID output is reached. This parameter is valid
for the PID set 1.
1
Ext PID min lim The process PID integration term is not decreased when the
output of the external PID has reached its minimum limit. In
this setup, the external PID is used as a source for the
process PID. This parameter is valid for the PID set 1.
2
No. Name/Value Description Def/FbEq16
