296 Parameters
40.06 Process PID status
word
Displays status information on process PID control.
This parameter is read-only.
0b0000
0b0000…0b1111 Process P ID co ntrol status word. 1 = 1
40.07 Process PID
operation mode
Activates/deactivates process PID control.
Note: Process PID control is only available in external
control; see section Local control vs. external control (page
33).
Off
Off Process PID control inactive. 0
On Process PID control active. 1
On when drive
running
Process PID control is active when the drive is running. 2
40.08 Set 1 feedback 1
source
Selects the primary source of process feedback. See the
control chain diagram on page 495.
AI2 percent
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value (see page 189). 1
AI2 scaled 12.22 AI2 scaled value (see page 191). 2
Freq in scaled 11.39 Freq in 1 scaled value (see page 187). 3
AI1 percent 12.101 AI1 percent value (see page 192)8
AI2 percent 12.102 AI2 percent value (see page 192)9
Feedback data
storage
40.91 Feedback data storage (see page 309), 10
Other Source selection (see Terms and abbreviations on page 162). -
40.09 Set 1 feedback 2
source
Selects the second source of process feedback. The second
source is used only if the setpoint function requires two
inputs.
For the selections, see parameter 40.08 Set 1 feedback 1
source.
Not selected
40.10 Set 1 feedback
function
Defines how process feedback is calculated from the two
feedback sources selected by parameters 40.08 Set 1
feedback 1 source and 40.09
Set 1 feedback 2 source.
In1
In1 Source 1. 0
No. Name/Value Description Def/FbEq16
Bit Name Value
0 PID active 1 = Process PID control active.
1 Setpoint frozen 1 = Process PID setpoint frozen.
2 Output frozen 1 = Process PID controller output frozen.
3 PID sleep mode 1 = Sleep mode active.
4 Sleep boost 1 = Sleep boost active.
5 Trim mode 1 = Trim mode active
6 Tracking mode 1 = Tracking function active.
7 Output limit high 1 = PID output is being limited by par. 40.37.
8 Output limit low 1 = PID output is being limited by par. 40.36.
9 Deadband active 1 = Deadband active (see parameter 40.39)
10 PID set 0 = Parameter set 1 in use. 1 = Parameter set 2 in use.
11 Reserved
12 Internal setpoint
active
1 = Internal setpoint active (see par. 40.16…40.23)
13…15 Reserved
