376 Additional parameter data
Fieldbus addresses
Refer to the User’s manual of the fieldbus adapter.
Binary src Binary source: the value of the parameter can be taken from a specific bit
in another parameter value (“Other”). Sometimes the value can be fixed to
0 (false) or 1 (true). In addition, the parameter may offer other pre-selected
settings.
Data Data parameter
FbEq32 32-bit fieldbus equivalent: The scaling between the value shown on the
panel and the integer used in communication when a 32-bit value is
selected for transmission to an external system.
The corresponding 16-bit scalings are listed in chapter Parameters (page
161).
List Selection list.
No. Parameter number.
PB Packed Boolean (bit list).
Real Real number.
Type Parameter type. See Analog src, Binary src, List, PB, Real.
Term Definition
