Parameters 193
12.110 AI dead band Defines dead-band area for analog input signals 12.11 AI1
actual value and 12.21 AI2 actual value.
For example, with dead-band as 0.40% and the default 12.18
AI1 max as 10.000 V, the dead-band range will be 0.00... 0.04
V. In addition, considering the hysteresis value of 10%, the
hysteresis negative value will be 0.036 V and the hysteresis
positive value will be 0.044 V.
Note: 10% of the AI dead-band value is internally added to
the firmware as AI dead-band hysteresis (positive and
negative). This value cannot be changed.
For more information on dead-band function and its
calculation, see section Dead-band function on page 97.
0.40%
0.00…100.00% Deadband for AI signals. 100 = 1%
13
13 Standard AO
Configuration of standard analog outputs.
13.02 AO force selection The source signals of the analog outputs can be overridden
for e.g. testing purposes. A forced value parameter is
provided for each analog output, and its value is applied
whenever the corresponding bit in this parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 13.02 and 13.11).
0b0000
0b0000…0b1111 Forced valu es sel ect or for analog outputs AO1 and AO2. 1 = 1
13.11 AO1 actual value Displays the value of AO1 in mA
This parameter is read-only.
-
0.000…22.000 mA Value of AO1. 1 = 1 mA
13.12 AO1 source Selects a signal to be connected to analog output AO1. Output
frequency
Zero None. 0
Motor speed used 01.01 Motor speed used (page 165). 1
Output frequency 01.06 Output frequency (page 165). 3
Motor current 01.07 Motor current (page 165). 4
Motor current % of
motor nominal
01.08 Motor current % of motor nom (page 165). 5
Motor torque 01.10 Motor torque (page 165). 6
DC voltage 01.11 DC voltage (page 165). 7
Output power 01.14 Output power (page 166). 8
Freq ref used 28.02 Frequency ref ramp output (page 240). 14
Process PID out 40.01 Process PID output actual (page 295). 16
Temp sensor 1
excitation
The output is used to feed an excitation current to the
temperature sensor 1, see parameter 35.11 Temperature 1
source. See also section Motor thermal protection (page 82).
20
No. Name/Value Description Def/FbEq16
Bit Value
0 1 = Force AO1 to value of parameter 13.13 AO1 forced value. (0 = Normal mode)
1 1 = Force AO2 to value of parameter 13.23 AO2 forced value. (0 = Normal mode)
2…15 Reserved
