ABB ACS560 - Page 381

Additional parameter data 381
11.4 2 Freq in 1 min Real 0…16000 Hz 1 = 1 Hz
11.4 3 Freq in 1 max Real 0…16000 Hz 1 = 1 Hz
11.44 Freq in 1 at scaled min Real -32768.000…32767.000 - 1000 = 1
11.45 Freq in 1 at scaled max Real -32768.000…32767.000 - 1000 = 1
12 Standard AI
12.02 AI force selection PB 0b000...0b1111 - 1 = 1
12.03 AI supervision function List 0…4 - 1 = 1
12.04 AI supervision selection PB 0b000...0b1111 - 1 = 1
12.11 AI1 actual value Real 0.000…11.000 V V 1000 = 1 unit
12.12 AI1 scaled value Real -32768.000…32767.000 - 1000 = 1
12.13 AI1 forced value Real 0.000…11.000 V V 1000 = 1 unit
12.15 AI1 unit selection List 2, 10 - 1 = 1
12.16 AI1 filter time Real 0.000…30.000 s 1000 = 1 s
12.17 AI1 min Real 0.000…11.000 V V 1000 = 1 unit
12.18 AI1 max Real 0.000…11.000 V V 1000 = 1 unit
12.19 AI1 scaled at AI1 min Real -32768.000…32767.000 - 1000 = 1
12.20 AI1 scaled at AI1 max Real -32768.000…32767.000 - 1000 = 1
12.21 AI2 actual value Real 0.000…22.000 mA 1000 = 1 unit
12.22 AI2 scaled value Real -32768.000…32767.000 - 1000 = 1
12.23 AI2 forced value Real 0.000…22.000 mA 1000 = 1 unit
12.25 AI2 unit selection List 2, 10 - 1 = 1
12.26 AI2 filter time Real 0.000…30.000 s 1000 = 1 s
12.27 AI2 min Real 0.000…22.000 mA 1000 = 1 unit
12.28 AI2 max Real 0.000…22.000 mA 1000 = 1 unit
12.29 AI2 scaled at AI2 min Real -32768.000…32767.000 - 1000 = 1
12.30 AI2 scaled at AI2 max Real -32768.000…32767.000 - 1000 = 1
12.101 AI1 percent value Real 0.00…100.00 % 100 = 1%
12.102 AI2 percent value Real 0.00…100.00 % 100 = 1%
12.110 AI dead band Real 0.00...100.00 % 1 = 1%
13 Standard AO
13.02 AO force selection PB 0b0000…0b1111 - 1 = 1
13.11 AO1 actual value Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.12 AO1 source Analog
src
--1 = 1
13.13 AO1 forced value Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.15 AO1 unit selection List 2, 10 - 1 = 1
13.16 AO1 filter time Real 0.000…30.000 s 1000 = 1 s
13.17 AO1 source min Real -32768.0…32767.0 - 10 = 1
13.18 AO1 source max Real -32768.0…32767.0 - 10 = 1
No. Name Type Range Unit FbEq32
