382 Additional parameter data
13.19 AO1 out at AO1 src min Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.20 AO1 out at AO1 src max Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.21 AO2 actual value Real 0.000…22.000 mA 1000 = 1 mA
13.22 AO2 source Analog
src
--1 = 1
13.23 AO2 forced value Real 0.000…22.000 mA 1000 = 1 mA
13.26 AO2 filter time Real 0.000…30.000 s 1000 = 1 s
13.27 AO2 source min Real -32768.0…32767.0 - 10 = 1
13.28 AO2 source max Real -32768.0…32767.0 - 10 = 1
13.29 AO2 out at AO2 src min Real 0.000…22.000 mA 1000 = 1 mA
13.30 AO2 out at AO2 src max Real 0.000…22.000 mA 1000 = 1 mA
13.91 AO1 data storage Real -327.68…327.67 - 100 = 1
13.92 AO2 data storage Real -327.68…327.67 - 100 = 1
19 Operation mode
19.01 Actual operation mode List --1 = 1
19.11 Ext1/Ext2 selection Binary
src
--1 = 1
19.12 Ext1 control mode List 1...5 - 1 = 1
19.14 Ext2 control mode List 1…5 - 1 = 1
19.16 Local control mode List 0, 1 - 1 = 1
19.17 Local control disable List 0…1 - 1 = 1
20 Start/stop/direction
20.01 Ext1 commands List 0…6, 4, 11, 12, 14 - 1 = 1
20.02 Ext1 start trigger type List 0…1 - 1 = 1
20.03 Ext1 in1 source Binary
src
--1 = 1
20.04 Ext1 in2 source Binary
src
--1 = 1
20.05 Ext1 in3 source Binary
src
--1 = 1
20.06 Ext2 commands List 0…6, 4, 11, 12, 14 - 1 = 1
20.07 Ext2 start trigger type List 0…1 - 1 = 1
20.08 Ext2 in1 source Binary
src
--1 = 1
20.09 Ext2 in2 source Binary
src
--1 = 1
20.10 Ext2 in3 source Binary
src
--1 = 1
20.11 Run enable stop mode List 0…2 - 1 = 1
20.12 Run enable 1 source Binary
src
--1 = 1
20.19 Enable start command Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
