Additional parameter data 383
20.21 Direction List 0…2 - 1 = 1
20.22 Enable to rotate Binary
src
--1 = 1
20.25 Jogging enable Binary
src
--1 = 1
20.26 Jogging 1 start source Binary
src
--1 = 1
20.27 Jogging 2 start source Binary
src
--1 = 1
21 Start/stop mode
21.01 Start mode List 0…2 - 1 = 1
21.02 Magnetization time Real 0…10000 ms 1 = 1 ms
21.03 Stop mode List 0…2 - 1 = 1
21.04 Emergency stop mode List 0…2 - 1 = 1
21.05 Emergency stop source Binary
src
--1 = 1
21.06 Zero speed limit Real 0.00...30000.00 rpm 100 = 1 rpm
21.07 Zero speed delay Real 0…30000 ms 1 = 1 ms
21.08 DC current control PB 0b0000…0b1111 - 1 = 1
21.09 DC hold speed Real 0.00…1000.00 rpm 100 = 1 rpm
21.10 DC current reference Real 0.0…100.0 % 10 = 1%
21.11 Post magnetization time Real 0…3000 s 1 = 1 s
21.14 Pre-heating input source Binary
src
--1 = 1
21.15 Pre-heating time delay Real 10...3000 s 1 = 1
21.16 Pre-heating current Real 0.0…30.0 % 10 = 1%
21.18 Auto restart time Real 0.0…10.0 s 10 = 1 s
21.19 Scalar start mode List 0…6 - 1 = 1
21.21 DC hold frequency Real 0.00…1000.00 Hz 100 = 1 Hz
21.22 Start delay Real 0.00…60.00 s 100 = 1 s
21.26 Torque boost current Real 15.0…300.0 % 100 = 1%
21.27 Torque boost time Real 0.0…60.0 s 10 = 1 s
21.30 Speed compensated stop
mode
Real 0…3 - 1 = 1
21.31 Speed comp stop delay Real 0.00…1000.00 s 100 = 1 s
21.32 Speed comp stop threshold Real 0…100 % 1 = 1%
21.34 Force auto restart List 0...1 - 1 = 1
22 Speed reference selection
22.01 Speed ref unlimited Real -30000.00…30000.00 rpm 100 = 1 rpm
22.11 Ext1 speed ref1 Analog
src
--1 = 1
22.12 Ext1 speed ref2 Analog
src
--1 = 1
22.13 Ext1 speed function List 0…5 - 1 = 1
No. Name Type Range Unit FbEq32
