384 Additional parameter data
22.18 Ext2 speed ref1 Analog
src
--1 = 1
22.19 Ext2 speed ref2 Analog
src
--1 = 1
22.20 Ext2 speed function List 0…5 - 1 = 1
22.21 Constant speed function PB 0b0000…0b1111 - 1 = 1
22.22 Constant speed sel1 Binary
src
--1 = 1
22.23 Constant speed sel2 Binary
src
--1 = 1
22.24 Constant speed sel3 Binary
src
--1 = 1
22.26 Constant speed 1 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.27 Constant speed 2 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.28 Constant speed 3 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.29 Constant speed 4 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.30 Constant speed 5 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.31 Constant speed 6 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.32 Constant speed 7 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.41 Speed ref safe Real -30000.00…30000.00 rpm 100 = 1 rpm
22.42 Jogging 1 ref Real -30000.00…30000.00 rpm 100 = 1 rpm
22.43 Jogging 2 ref Real -30000.00…30000.00 rpm 100 = 1 rpm
22.51 Critical speed function PB 0b0000…0b1111 - 1 = 1
22.52 Critical speed 1 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.53 Critical speed 1 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.54 Critical speed 2 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.55 Critical speed 2 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.56 Critical speed 3 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.57 Critical speed 3 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.71 Motor potentiometer function List 0…3 - 1 = 1
22.72 Motor potentiometer initial
value
Real -32768.00…32767.00 - 100 = 1
22.73 Motor potentiometer up source Binary
src
--1 = 1
22.74 Motor potentiometer down
source
Binary
src
--1 = 1
22.76 Motor potentiometer min value Real -32768.00…32767.00 - 100 = 1
22.77 Motor potentiometer max
value
Real
-32768.00…32767.00 - 100 = 1
22.78 Motor potentiometer ramp up Real 0.0...3600.0 s -
22.79 Motor potentiometer ramp
down
Real 0.0...3600.0 s -
22.80 Motor potentiometer ref act Real -32768.00…32767.00 - 100 = 1
22.86 Speed reference act 6 Real -30000.00…30000.00 rpm 100 = 1 rpm
No. Name Type Range Unit FbEq32
