Additional parameter data 395
40.26 Set 1 setpoint min Real -200000.00...200000.00 - 100 = 1
40.27 Set 1 setpoint max Real -200000.00...200000.00 - 100 = 1
40.28 Set 1 setpoint increase time Real 0.0…1800.0 s 10 = 1 s
40.29 Set 1 setpoint decrease time Real 0.0…1800.0 s 10 = 1 s
40.30 Set 1 setpoint freeze enable Binary
src
--1 = 1
40.31 Set 1 deviation inversion Binary
src
--1 = 1
40.32 Set 1 gain Real 0.01…100.00 - 100 = 1
40.33 Set 1 integration time Real 0.0…9999.0 s 10 = 1 s
40.34 Set 1 derivation time Real 0.000…10.000 s 1000 = 1 s
40.35 Set 1 derivation filter time Real 0.0…10.0 s 10 = 1 s
40.36 Set 1 output min Real -200000.00…200000.00 - 10 = 1
40.37 Set 1 output max Real -200000.00…200000.00 - 10 = 1
40.38 Set 1 output freeze Binary
src
--1 = 1
40.39 Set 1 deadband range Real 0.0...3600.0 - 10 = 1
40.40 Set 1 deadband delay Real 0.0...200000.0 s 10 = 1 s
40.43 Set 1 sleep level Real 0.0…200000.0 - 10 = 1
40.44 Set 1 sleep delay Real 0.0…3600.0 s 10 = 1 s
40.45 Set 1 sleep boost time Real 0.0…3600.0 s 10 = 1 s
40.46 Set 1 sleep boost step Real 0.0…200000.0 PID
customer
units
10 = 1 PID
customer unit
40.47 Set 1 wake-up deviation Real -20000000…200000.00 PID
customer
units
100 = 1 PID
customer unit
40.48 Set 1 wake-up delay Real 0.00…60.00 s 100 = 1 s
40.49 Set 1 tracking mode Binary
src
--1 = 1
40.50 Set 1 tracking ref selection Analog
src
--1 = 1
40.51 Set 1 trim mode List 0...3 - 1 = 1
40.52 Set 1 trim selection List 1...3 - 1 = 1
40.53 Set 1 trimmed ref pointer Analog
src
--1 = 1
40.54 Set 1 trim mix Real 0.000...1.000 - 1 = 1
40.55 Set 1 trim adjust Real -100.000...100.000 - 1 = 1
40.56 Set 1 trim source List 1...2 - 1 = 1
40.57 PID set1/set2 selection Binary
src
0...7, 18...23 - 1 = 1
40.58 Set 1 increase prevention Binary
src
0...3 - 1 = 1
40.59 Set 1 decrease prevention Binary
src
0...3 - 1 = 1
No. Name Type Range Unit FbEq32
