396 Additional parameter data
40.60 Set 1 PID activation source Binary
src
--1 = 1
40.61 Setpoint scaling actual Real --200000.00…200000.00 - 100 = 1
40.62 PID internal setpoint actual Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
40.65 Trim auto connection TBD
40.79 Set 1 units List 0...31 Depends
on
selection
-
40.80 Set 1 PID output min source Analog
src
--1 = 1
40.81 Set 1 PID output max source Analog
src
--1 = 1
40.89 Set 1 setpoint multiplier Real -200000.00…200000.00 - -
40.90 Set 1 feedback multiplier Real -200000.00…200000.00 - 100 = 1
40.91 Feedback data storage Real -327.68…327.67 - 100 = 1
40.92 Setpoint data storage Real -327.68…327.67 - 100 = 1
40.96 Process PID output% Real -100.00...100.00 % -
40.97 Process PID feedback% Real -100.00...100.00 % -
40.98 Process PID setpoint% Real -100.00...100.00 % -
40.99 Process PID deviation% Real -100.00...100.00 % -
41 Process PID set 2
41.08 Set 2 feedback 1 source Analog
src
--1 = 1
41.09 Set 2 feedback 2 source Analog
src
--1 = 1
41.10 Set 2 feedback function List 0…11 - 1 = 1
41.11 Set 2 feedback filter time Real 0.000…30.000 s 1000 = 1 s
41.14 Set 2 setpoint scaling Real -200000.00 … 200000.00 - 100=1
41.15 Set 2 output scaling Real -200000.00 … 200000.00 - 100=1
41.16 Set 2 setpoint 1 source Analog
src
--1 = 1
41.17 Set 2 setpoint 2 source Analog
src
--1 = 1
41.18 Set 2 setpoint function List 0…11 - 1 = 1
41.19 Set 2 internal setpoint sel1 Binary
src
--1 = 1
41.20 Set 2 internal setpoint sel2 Binary
src
--1 = 1
41.21 Set 2 internal setpoint 1 Real
-200000.00 … 200000.00
PID
customer
unit
100 = 1 PID
customer unit
41.22 Set 2 internal setpoint 2 Real
-200000.00 … 200000.00
PID
customer
units
100 = 1 PID
customer unit
No. Name Type Range Unit FbEq32
