Additional parameter data 397
41.23 Set 2 internal setpoint 3 Real
-200000.00 … 200000.00
PID
customer
units
100 = 1 PID
customer unit
41.24 Set 2 internal setpoint 0 Real
-200000.00 … 200000.00
PID
customer
units
100 = 1 PID
customer unit
41.26 Set 2 setpoint min Real -200000.00 … 200000.00 - 100 = 1
41.27 Set 2 setpoint max Real -200000.00 … 200000.00 - 100 = 1
41.28 Set 2 setpoint increase time Real 0.0…1800.0 s 10 = 1 s
41.29 Set 2 setpoint decrease time Real 0.0…1800.0 s 10 = 1 s
41.30 Set 2 setpoint freeze enable Binary
src
--1 = 1
41.31 Set 2 deviation inversion Binary
src
--1 = 1
41.32 Set 2 gain Real 0.01…100.00 - 100 = 1
41.33 Set 2 integration time Real 0.0…9999.0 s 10 = 1 s
41.34 Set 2 derivation time Real 0.000…10.000 s 1000 = 1 s
41.35 Set 2 derivation filter time Real 0.0…10.0 s 10 = 1 s
41.36 Set 2 output min Real -200000.00 … 200000.00 - 10 = 1
41.37 Set 2 output max Real -200000.00 … 200000.00 - 10 = 1
41.38 Set 2 output freeze Binary
src
--1 = 1
41.39 Set 2 deadband range Real 0.0...3600.0 - 10 = 1
41.40 Set 2 deadband delay Real 0.0...200000.0 s 10 = 1 s
41.43 Set 2 sleep level Real 0.0…200000.0 - 10 = 1
41.44 Set 2 sleep delay Real 0.0…3600.0 s 10 = 1 s
41.45 Set 2 sleep boost time Real 0.0…3600.0 s 10 = 1 s
41.46 Set 2 sleep boost step Real 0.0…200000.0 PID
customer
units
10 = 1 PID
customer unit
41.47 Set 2 wake-up deviation Real
-200000.00 … 200000.00
PID
customer
units
100 = 1 PID
customer unit
41.48 Set 2 wake-up delay Real 0.00…60.00 s 100 = 1 s
41.49 Set 2 tracking mode Binary
src
--1 = 1
41.50 Set 2 tracking ref selection Analog
src
--1 = 1
41.51 Set 2 trim mode List 0...3 - 1 = 1
41.52 Set 2 trim selection List 1...3 - 1 = 1
41.53 Set 2 trimmed ref pointer Analog
src
--1 = 1
41.54 Set 2 trim mix Real 0.000...1.000 - 1 = 1
41.55 Set 2 trim adjust Real -100.000...100.000 - 1 = 1
41.56 Set 2 trim source List 1...2 - 1 = 1
No. Name Type Range Unit FbEq32
