Parameters 305
AI2 scaled 12.22 AI2 scaled value (see page 191). 2
FB A ref1 03.05 FB A reference 1 (see page 168). 3
FB A ref2 03.06 FB A reference 2 (see page 168). 4
Other Source selection (see Terms and abbreviations on page 162). -
40.51 Set 1 trim mode Activates the trim function and selects between direct and
proportional trimming (or a combination of both). With
trimming, it is possible to apply a corrective factor to the drive
reference (setpoint). The output after trimming is available as
parameter 40.05 Process PID trim output act .
Off
Off The trim function is inactive. 0
Direct The trim function is active. The trimming factor is relative to
the maximum speed, torque or frequency; the selection
between these is made by parameter 40.52 Set 1 trim
selection.
1
Proportional The trim function is active. The trimming factor is relative to
the reference selected by parameter 40.53 Set 1 trimmed ref
pointer.
2
Combined The trim function is active. The trimming factor is a
combination of both Direct and Proportional modes; the
proportions of each are defined by parameter 40.54 Set 1 trim
mix.
3
40.52 Set 1 trim selection Selects whether trimming is used for correcting the speed,
torque or frequency reference.
Speed
Torque Torque reference trimming. 1
Speed Speed reference trimming. 2
Frequency Frequency reference trimming. 3
40.53 Set 1 trimmed ref
pointer
Selects the signal source for the trim reference. Not selected
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value (see page 189). 1
AI2 scaled 12.22 AI2 scaled value (see page 191). 2
FBA ref1 03.05 FB A reference 1 (see page 168). 3
FBA ref2 03.06
FB A reference 2 (see page 168). 4
Other Source selection (see Terms and abbreviations). -
40.54 Set 1 trim mix When parameter 40.51 Set 1 trim mode is set to Combined,
defines the effect of direct and proportional trim sources in the
final trimming factor.
0.000 = 100% proportional
0.500 = 50% proportional, 50% direct
1.000 = 100% direct
0.000
0.000...1.000 Trim mix. 1 = 1
40.55 Set 1 trim adjust Defines a multiplier for the trimming factor. This value is
multiplied by the result of parameter 40.51 Set 1 trim mode.
Consequently, the result of the multiplication is used to
multiply the result of parameter 40.56 Set 1 trim adjust.
1.000
-100.000...100.000 Multiplier for trimming factor. 1 = 1
40.56 Set 1 trim source Selects the reference to be trimmed. PID output
PID ref PID setpoint. 1
No. Name/Value Description Def/FbEq16
