118 Control macros
Terminal sizes
• (frames R0…R8): 0.14…1.5 mm
2
(all terminals)
• Tightening torques: 0.5…0.6 N·m (0.4 lbf·ft)
Notes
1)
The signal source is powered externally. See the manufacturer’s instructions. To
use sensors supplied by the drive aux. voltage output, see chapter Electrical
installation, section Connection examples of two-wire and three-wire sensors in the
Hardware manual of the drive
2)
If Constant frequency is activated it overrides the reference from the PID controller
output.
3)
The internal setpoint are set based on the combination of sources as follows:
4)
Ground the outer shield of the cable 360 degrees under the grounding clamp on
the grounding shelf for the control cables.
5)
Connected with jumpers at the factory.
6)
Total load capacity of the auxiliary voltage output +24V (X2:10) = 6.0 W (250 mA /
24 V). User can use this source for either of the I/O connections (DI1... DI2- RO1 or
DI3...DI6 - RO2
~RO3).
7)
Input signal
8)
Output signal
9)
For R0...R2 frames only
In addition, below inputs are set automatically as follows:
For information on cable connection and drive operation, see Control Connections in
the Hardware manual (3AXD50000044998).
Source defined
by par. 40.19
Source defined
by par. 40.20
Internal setpoint active
DI2 DI3
0 0 Setpoint source: AI1
10Set 1 internal setpoint 1
01Set 1 internal setpoint 2
11Set 1 internal setpoint 3
Parameter No.
Name
(Input/Setting)
Value
20.01 Ext1 commands 1= In1 Start
23.11 Ramp set selection 0 = Acc/Dec time 1
