378 Additional parameter data
01.67 Abs output power % drive nom Real 0.00…300.00 % 100 = 1%
01.68 Abs motor shaft power Real 0.00…32767.00 kW or hp 100 = 1 kW
03 Input references
03.01 Panel reference Real -10000.00…100000.00
- 100 = 1
03.02 Panel reference remote Real -10000.00…100000.00 - 100 = 1
03.05 FB A reference 1 Real -10000.00…100000.00 - 100 = 1
03.06 FB A reference 2 Real -10000.00…100000.00 - 100 = 1
03.09 EFB reference 1 Real -30000.00…30000.00 - 100 = 1
03.10 EFB reference 2 Real -30000.00…30000.00 - 100 = 1
04 Warnings and faults
04.01 Tripping fault Data 0x0000...0xffff - 1 = 1
04.02 Active fault 2 Data 0x0000...0xffff - 1 = 1
04.03 Active fault 3 Data 0x0000...0xffff - 1 = 1
04.06 Active warning 1 Data 0x0000...0xffff - 1 = 1
04.07 Active warning 2 Data 0x0000...0xffff - 1 = 1
04.08 Active warning 3 Data 0x0000...0xffff - 1 = 1
04.11 Latest fault Data 0x0000...0xffff - 1 = 1
04.12 2nd latest fault Data 0x0000...0xffff - 1 = 1
04.13 3rd latest fault Data 0x0000...0xffff - 1 = 1
04.16 Latest warning Data 0x0000...0xffff - 1 = 1
04.17 2nd latest warning Data 0x0000...0xffff - 1 = 1
04.18 3rd latest warning Data 0x0000...0xffff - 1 = 1
04.40 Event word 1 PB 0000h…FFFFh - 1 = 1
04.40 Event word 1 PB 0000h…FFFFh - 1 = 1
04.41 Event word 1 bit 0 code Data 0x2310…FFFFh - 1 = 1
04.43 Event word 1 bit 1 code Data 0x3210…FFFFh - 1 = 1
04.45,
04,47,
04,49,
…
…………
04.71 Event word 1 bit 15 code Data 0x2330…FFFFh - 1 = 1
05 Diagnostics
05.01 On-time counter Real 0…65535 d 1 = 1 d
05.02 Run-time counter Real 0…65535 d 1 = 1 d
05.03 Hours run Real 0.0…429496729.5 h 10 = 1 h
05.04 Fan on-time counter Real 0…65535 d 1 = 1 d
05.10 Control board temperature Real -100…300 °C 10 = 1 °
05.11 Inverter temperature Real -40.0…160.0 % 10 = 1%
05.20 Diagnostic word 1 PB 0b0000...0b1111 - 0 b0000
05.21 Diagnostic word 2 PB 0b0000...0b1111 - 0 b0000
05.22 Diagnostic word 3 PB 0b0000...0b1111 - 0 b0000
05.80 Motor speed at fault Real -30000.00…30000.00 rpm 100 = 1 rpm
No. Name Type Range Unit FbEq32
