Additional parameter data 387
28.22 Constant frequency sel1 Binary
src
--1 = 1
28.23 Constant frequency sel2 Binary
src
--1 = 1
28.24 Constant frequency sel3 Binary
src
--1 = 1
28.26 Constant frequency 1 Real -500.00…500.00 Hz 100 = 1 Hz
28.27 Constant frequency 2 Real -500.00…500.00 Hz 100 = 1 Hz
28.28 Constant frequency 3 Real -500.00…500.00 Hz 100 = 1 Hz
28.29 Constant frequency 4 Real -500.00…500.00 Hz 100 = 1 Hz
28.30 Constant frequency 5 Real -500.00…500.00 Hz 100 = 1 Hz
28.31 Constant frequency 6 Real -500.00…500.00 Hz 100 = 1 Hz
28.32 Constant frequency 7 Real -500.00…500.00 Hz 100 = 1 Hz
28.41 Frequency ref safe Real -500.00…500.00 Hz 100 = 1 Hz
28.42 Jogging 1 frequency ref Real -500.00…500.00 Hz 100 = 1 Hz
28.43 Jogging 2 frequency ref Real -500.00…500.00 Hz 100 = 1 Hz
28.51 Critical frequency function PB 0b0000…0b1111 - 1 = 1
28.52 Critical frequency 1 low Real -500.00…500.00 Hz 100 = 1 Hz
28.53 Critical frequency 1 high Real -500.00…500.00 Hz 100 = 1 Hz
28.54 Critical frequency 2 low Real -500.00…500.00 Hz 100 = 1 Hz
28.55 Critical frequency 2 high Real -500.00…500.00 Hz 100 = 1 Hz
28.56 Critical frequency 3 low Real -500.00…500.00 Hz 100 = 1 Hz
28.57 Critical frequency 3 high Real -500.00…500.00 Hz 100 = 1 Hz
28.71 Freq ramp set selection Binary
src
--1 = 1
28.72 Freq acceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
28.73 Freq deceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
28.74 Freq acceleration time 2 Real 0.000…1800.000 s 1000 = 1 s
28.75 Freq deceleration time 2 Real 0.000…1800.000 s 1000 = 1 s
28.76 Freq ramp in zero source Binary
src
--1 = 1
28.82 Shape time 1 Real 0.000…1800.000 s 1000 = 1 s
28.83 Shape time 2 Real 0.000…1800.000 s 1000 = 1 s
28.92 Frequency ref act 3 Real -500.00…500.00 Hz 100 = 1 Hz
28.96 Frequency ref act 7 Real -500.00…500.00 Hz 100 = 1 Hz
28.97 Frequency ref unlimited Real -500.00…500.00 Hz 100 = 1 Hz
30 Limits
30.01 Limit word 1 PB 0b0000…0b1111 - 1 = 1
30.02 Torque limit status PB 0b0000…0b1111 - 1 = 1
30.09 Current limit monitor time Real 0.00...120.00 s -
30.10 Current limit actions List 0...2 - 1=1
30.11 Minimum speed Real -30000.00…30000.00 rpm 100 = 1 rpm
30.12 Maximum speed Real -30000.00…30000.00 rpm 100 = 1 rpm
No. Name Type Range Unit FbEq32
