390 Additional parameter data
32.30 Supervision 3 high Real -21474836.00…
21474836.00
- 100 = 1
32.31 Supervision 3 hysteresis Real 0.00…100000.00 - 100 = 1
32.35 Supervision 4 function List 0…7 - 1 = 1
32.36 Supervision 4 action List 0…3 - 1 = 1
32.37 Supervision 4 signal Analog
src
--1 = 1
32.38 Supervision 4 filter time Real 0.000…30.000 s 1000 = 1 s
32.39 Supervision 4 low Real -21474836.00…
21474836.00
- 100 = 1
32.40 Supervision 4 high Real -21474836.00…
21474836.00
- 100 = 1
32.41 Supervision 4 hysteresis Real 0.00…100000.00 - 100 = 1
32.45 Supervision 5 function List 0…7 - 1 = 1
32.46 Supervision 5 action List 0…3 - 1 = 1
32.47 Supervision 5 signal Analog
src
--1 = 1
32.48 Supervision 5 filter time Real 0.000…30.000 s 1000 = 1 s
32.49 Supervision 5 low Real -21474836.00…
21474836.00
- 100 = 1
32.50 Supervision 5 high Real -21474836.00…
21474836.00
- 100 = 1
32.51 Supervision 5 hysteresis Real 0.00…100000.00 - 100 = 1
32.55 Supervision 6 function List 0…7 - 1 = 1
32.56 Supervision 6 action List 0…3 - 1 = 1
32.57 Supervision 6 signal Analog
src
--1 = 1
32.58 Supervision 6 filter time Real 0.000…30.000 s 1000 = 1 s
32.59 Supervision 6 low Real -21474836.00…
21474836.00
- 100 = 1
32.60 Supervision 6 high Real -21474836.00…
21474836.00
- 100 = 1
32.61 Supervision 6 hysteresis Real 0.00…100000.00 - 100 = 1
34 Timed functions
34.01 Timed functions status PB 0b0000…0b1111 - 1 = 1
34.02 Timer status PB 0b0000…0b1111 - 1 = 1
34.04 Season/exception day status PB 0b0000…0b1111 - 1 = 1
34.10 Timed functions enable Binary
src
0...7 - 1 = 1
34.11 Timer 1 configuration PB 0b0000…0b1111 - 1 = 1
34.12 Timer 1 start time Time 00:00:00…23:59:59 - 1 = 1
34.13 Timer 1 duration Duration 00 00:00…07 00:00 - 1 = 1
34.14 Timer 2 configuration PB 0b0000…0b1111 - 1 = 1
34.15 Timer 2 start time Time 00:00:00…23:59:59 - 1 = 1
34.16 Timer 2 duration Duration 00 00:00…07 00:00 - 1 = 1
No. Name Type Range Unit FbEq32
