ABB ACS880-604

Fuses
Brake resistor fuses (IEC and UL)DC fuses (IEC and UL)ACS880-604-…
QtyDataTypeQtyDataType
U
N
= 400 V
3500 A; 690 V170M64082630 A; 690 V170M64100500-3
3800 A; 690 V170M641221000 A; 690 V170M64140750-3
6500 A; 690 V170M64084630 A; 690 V170M64101000-3
6800 A; 690 V170M641241000 A; 690 V170M64141510-3
9800 A; 690 V170M641261000 A; 690 V170M64142260-3
12800 A; 690 V170M641281000 A; 690 V170M64143010-3
15800 A; 690 V170M6412101000 A; 690 V170M64143770-3
U
N
= 500 V
3500 A; 690 V170M64082630 A; 690 V170M64100630-5
3800 A; 690 V170M641221000 A; 690 V170M64140940-5
6500 A; 690 V170M64084630 A; 690 V170M64101260-5
6800 A; 690 V170M641241000 A; 690 V170M64141880-5
9800 A; 690 V170M641261000 A; 690 V170M64142830-5
12800 A; 690 V170M641281000 A; 690 V170M64143770-5
15800 A; 690 V170M6412101000 A; 690 V170M64144710-5
U
N
= 690 V
3500 A; 1250 V170M65422630 A; 1250 V170M65440870-7
3800 A; 1250 V170M654621000 A; 1100 V170M65481300-7
6500 A; 1250 V170M65424630 A; 1250 V170M65441730-7
6800 A; 1250 V170M654641000 A; 1100 V170M65482600-7
9800 A; 1250 V170M654661000 A; 1100 V170M65483900-7
12800 A; 1250 V170M654681000 A; 1100 V170M65485200-7
15800 A; 1250 V170M6546101000 A; 1100 V170M65486500-7
Allowable mounting orientations
The modules must be mounted upright or on right-hand side (viewed from the front).
Dimensions and weights
WeightDepthWidthHeightFrame
lbkginmminmminmm
275125235839.4240551397R8i
