15. Example circuit diagrams
Contents of this chapter
This chapter contains connection diagram examples for frame 1×R8i brake units.
Note: The Safe torque off (STO) function is not in use, and has been bridged at the factory
as shown in the diagrams.
Component designations used in the diagrams
ComponentDesignation
BCU control unitA41
FDPI board, included in a DPMP-01 panel mounting platform kit (to be ordered separately)A48
ACS-AP-W control panelA49
DC fusesF11.xx
Brake moduleT11.x
External 24 V DC power supplyT22
Example circuit diagrams 129
