ABB ACS880-604

Free space requirements
Left / RightFrontBelowAboveFrame
inmminmminmminmm
0.4100.410--7.9200R8i
Definitions
Free space to enable cooling air flowAbove
Free space for cablingFront
Free space for smooth installationLeft
Free space for smooth installationRight
Losses, cooling data and noise
Cooling air flowLossesNoise levelACS880-604-...
ft
3
/minm
3
/hkWdB (A)
U
N
= 400 V
76513003.1720500-3
76513004.8720750-3
153026006.3741000-3
153026009.7741510-3
2295390014.5762260-3
3060520019.3763010-3
3825650024.1773770-3
U
N
= 500 V
76513003.3720630-5
76513005.0720940-5
153026006.6741260-5
1530260010.0741880-5
2295390015.0762830-5
3060520020.0763770-5
3825650025.1774710-5
U
N
= 690 V
76513004.2720870-7
76513006.3721300-7
153026008.4741730-7
1530260012.6742600-7
2295390018.9763900-7
3060520025.2765200-7
3825650031.5776500-7
