ABB ACS880-604

IllustrationKit codeOrdering codeQtyEnclosureFrame
size
A-468-8-216-
VX
3AXD500004890911600 mmR8i
Instruction code:
3AXD50000493265
￭ DC fuses
DC fuses protect the module and drive DC bus against short circuits. Fuse kits are available
for modules of frame size R8i.
The fuses listed below are size 3.
Fuse (IEC and UL)
Brake unit type
Ordering codeDataQtyType
U
N
= 400 V
68335418630 A; 690 V2×2170M6410ACS880-604-0500-3
683332961000 A; 690 V2×2170M6414ACS880-604-0750-3
68335418630 A; 690 V2×4170M6410ACS880-604-1000-3
683332961000 A; 690 V2×4170M6414ACS880-604-1510-3
683332961000 A; 690 V2×6170M6414ACS880-604-2260-3
683332961000 A; 690 V2×8170M6414ACS880-604-3010-3
683332961000 A; 690 V2×10170M6414ACS880-604-3770-3
U
N
= 500 V
68335418630 A; 690 V2×2170M6410ACS880-604-0630-5
683332961000 A; 690 V2×2170M6414ACS880-604-0940-5
68335418630 A; 690 V2×4170M6410ACS880-604-1260-5
683332961000 A; 690 V2×4170M6414ACS880-604-1880-5
683332961000 A; 690 V2×6170M6414ACS880-604-2830-5
683332961000 A; 690 V2×8170M6414ACS880-604-3770-5
683332961000 A; 690 V2×10170M6414ACS880-604-4710-5
U
N
= 690 V
63903167630 A; 1250 V2×2170M6544ACS880-604-0870-7
639167491000 A; 1100 V2×2170M6548ACS880-604-1300-7
63903167630 A; 1250 V2×4170M6544ACS880-604-1730-7
639167491000 A; 1100 V2×4170M6548ACS880-604-2600-7
639167491000 A; 1100 V2×6170M6548ACS880-604-3900-7
639167491000 A; 1100 V2×8170M6548ACS880-604-5200-7
639167491000 A; 1100 V2×10170M6548ACS880-604-6500-7
86 Ordering information
